HOWO 4X4 Dump Truck
HOWO 4X4 dump truck For Sale
The HOWO 4X4 dump truck is powerful. It’s suited for many terrains. It’s particularly good for complex and rugged roads. It has a YN4102QBZL engine that gives 130 hp. The 4X4 drive and WLY5T46 transmission ensure good performance. They also ensure maneuverability in many road conditions. The vehicle has a compact design. It features an 1880mm wide single cockpit. The cockpit has built-in air conditioning, a multimedia system, and electric windows. These features provide a comfortable driving experience. The wheelbase is 3250mm. The vehicle is 7545x2550x3400mm. It offers good maneuverability and stability. Its tipping bucket is 3600x2100x800mm. This, combined with the efficient lifting system, makes the loading and unloading easier. This HOWO 4X4 tipper truck is an ideal solution for demanding transport tasks.
Specification
| Truck Model | ZZ3048D3224C143/J5B-4102TN23S2065MDMC Dumper(Left/ Right Hand Driving Type Optional) |
| Engine | Model: YN4102QBZL, 4 cylinders in line, turbocharged, intercooler, Euro 2, 130 HP |
| 4-cylinder in-line with water cooling, turbo-charging and intercooling | |
| Displacement: 4.726 L | |
| Drive type | 4X4 |
| Gearbox | WLY5T46, LS3213, 5 forwards & 1 reverse, with Power Take-Off (PTO) |
| Cabin | 1880mm single cabin, A/C, Radio FM with USB, Right-hand drive, Rear view camera, MP5, Power window with central control lock, HOWO cover |
| Axles | 2.0T/6.5T |
| Chassis Section | 230×(6+5) mm |
| Braking System | Dual circuit compressed air brake |
| Tires | 8.25R16×7, rear axle with double tires |
| Fuel Tank Volume (L) | 120 L, iron tank |
| Dead Weight | 6548 |
| Gross Vehicle Weight (kg) | 16000 |
| Rated Loading Weight (kg) | 9865 |
| Wheelbase (mm) | 3250 |
| Min.Ground Clearance (mm) | 314 |
| Approach/Depart Angle(°) | 19/ (27/65) |
| Gradeability (%) | ≥50 |
| Min. Turning Diameter (m) | 15 |
| Cargo Body Size (LxWxH) (mm) | 3600×2100×800mm, bottom 4mm, side 3mm |
| Lifting System | φ140 single plunger Steering: Power steering |
| Others | Exhaust brake, Clutch booster. |
| Overall Dimension(LxWxH) (mm) | 545x2550x3400 |
