HOWO 4X2 Heavy Duty Tanker Truck
HOWO 4X2 Heavy Duty Tanker Truck For Sale
The SINOTRUK/HOWO 4X2 Heavy Duty Tanker Truck is a versatile and powerful liquid transport vehicle. It is equipped with a 12 cubic meter tank made from durable Q235 material. It supports pressure and gravity unloading. The tank has safety features, such as a fire extinguisher. It measures 8,190 x 2,550 x 3,650 mm. It’s powered by a WD615.87 (Euro II) 290 hp engine. This balance of size and power suits heavy-duty tasks. The design emphasizes safety, performance, and driver comfort. It has a 10 forward and 2 reverse drive system, dual circuit compressed air brakes, and ZF8198 hydraulic steering with power assist. It currently serves in various fields, such as agriculture, the chemical industry, and petroleum.
Specification
| Truck Model | ZZ1167M4611W(Left Hand Drive/right hand drive ) |
| Truck Brand | SINOTRUK-HOWO |
| Dimension (LxWxH) (unloaded)mm | 8190×2550×3650 |
| Tank volume(m³) | Tank volume: 12m³ , 1 separated tank, head 5mm, body 5mm,material Q235; |
| Subsea valve: 1 position;2 units 4m 4″ hose. | |
| Other: pressure unloading, gravity unloading, towing wire, fire caps, | |
| fire extinguishers. Vehicle spray wax. | |
| Approaching angle/ Departure angel (°) | 16/15 |
| Overhang (front/rear) (mm) | 1500/1890 |
| Wheel base (mm) | 4600 |
| Max. Driving speed (km/h) | 95 |
| Front axle loading capacity (kg) | 7000 |
| Rear axle loading capacity(kg) | 16000 |
| Curb weight (kg) | 8990 |
| Gross vehicle weight | 16000 |
| Cab Model | SINOTRUK HW76 Lengthen cab,single bunk,all steel forward control, 55o hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, |
| laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system,adjustable roof flap, with stereo radio/MP3, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt, air conditioner,left hand driving. | |
| Engine Model | |
| Model | WD615.87(EURO II),290hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, |
| direct injection | |
| Rated Power(kw/rpm) | 213/2200 |
| Mark | Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 71ºC opening begin, Rigid fan |
| Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance |
| Transmission Model | SINOTRUK HW13710 transmission ,10 forward and 2 reverse |
| Brake system | |
| Service brake | Dual circuit compressed air brake |
| Parking Brake | Spring energy, compressed |
| (emergency brake) | |
| Steering system Model | ZF8198 Steering Gear Box ,hydraulic steering with power assistance. |
| (Left hand driving/right hand drive) | |
| Front axle | SINOTRUK 7000kg Front Axle,new 7-ton front axles of equipped with drum brakes. |
| Rear axle | SINOTRUK 16000kg Double Reduction Drive Axle, Pressed axle housing, central single reduction with planetary wheel reduction and with differential locks |
| between wheels and axles,ratio:4.42;strengthened design, loading capacity and reliability have been increased greatly. | |
| Wheels &Tire | Rims:9.0-22.5 10 hole-steel ;Tyres:12R22.5 tubeless tyre with 1 Spare tire. |
| Electrical system | |
| Electrics Operating voltage | 24V,negative grounded |
| Starter | 24V,7.5 Kw |
| Alternator | 3-phase,28V,1500 W |
| Batteries | 2×12 V,165 Ah |
| others | horn,headlamps,fog lights,brake lights,indicators and reverse light. |
| Oil Tank | Square type-400L Aluminum alloy fuel tank |
| Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable |
| for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust | |
| according to the special needs of the commodity. | |
