Shacman H3000 Dump Truck 6X4
Shacman H3000 Dump Truck6X4 For Sale
The Shacman H3000 Dump Truck 6X4 offers a loading capacity of 30 tonnes, making it ideal for heavy haulage tasks. It can handle the transport of a wide range of materials such as ore, sand, gravel or coal. The engine is Weichai’s WP10.380E22 engine, which meets Euro 2 emission standards and is capable of delivering a sustained 400 hp. Driver comfort is also taken into account in the cab, which includes air conditioning for long-distance driving. MAN technology on the 9.5T front axle and 16T rear axle, supplemented by drum brakes, enhances the truck’s stability and control. It is a high-quality, highly functional and economical transport vehicle.
Specification
| Specification | Detail |
| Price | $40,000 (Negotiable) |
| Engine Model | WP12.400E201 |
| Horsepower | 400 hp |
| Emission Standard | Euro 2 |
| Cabin Type | H3000 long cabin |
| Air Conditioning | Included |
| Axles | Front: 9.5T, Rear: MAN 16T |
| Brakes | Drum brake |
| Tires | 12.00R20/14.00R20/315/80R22.5 |
| Spares | 10+1 pecs |
| Wheelbase (mm) | 3775+1400 |
| Max Speed (km/h) | 75 |
| Transmission | FAST 10JSD180T-B-QH50 |
| Front Axle | HANDE MAN 9.5T |
| Rear Axle | HANDE 16T MAN double reduction |
| Speed Ratio | 5.262 |
| Clutch | Ø430 diaphragm |
| Steering | ZF technology |
| Frame | 850×300(8+7) |
| Suspension | Multi-leaf spring |
| Fuel Tank Capacity | 400L Aluminum alloy |
| Wheels and Tires | 12.00R20 |
| Brake System | Dual circuit compressed air brake |
| Cabin Features | Air suspended main seat, electronically controlled A/C, metal bumpers, etc. |
| Upbody Dimensions (mm) | 5800x2300x1500 |
